Understanding feColorMatrix SVG Filters

Published

In my last post about chromatic aberration with SVG filters, I showed how to create an SVG/CSS-only effect that used <feColorMatrix> to isolate RGB color channels. Honestly, <feColorMatrix> is pretty complicated and deserves a whole own post on its own.

For those wondering, SVG filter effects are filter elements that make up the resulting effect. That’s where the fe prefix comes from on SVG tags like <feTile> and <feMerge>.

With <feColorMatrix>, you can make photo-editor style color effects:

SVG
<feColorMatrix type="matrix" values="
  1 0 0 0 0
  0 1 0 0 0
  0 0 1 0 0
  0 0 0 1 0
" />

Matrix values

The hardest part of using <feColorMatrix> is learning how to use the matrix attribute. In the following “default” matrix, the effect will output exactly the same colors as its input:

Plain Text
1 0 0 0 0
0 1 0 0 0
0 0 1 0 0
0 0 0 1 0

From top to bottom, rows in the matrix control a color channel from the target element:

  1. Red
  2. Green
  3. Blue
  4. Alpha (transparency)

From left to right, columns of each row represent:

  1. Red × channel color
  2. Green × channel color
  3. Glue × channel color
  4. Alpha (transparency) × channel color
  5. Offset (add or subtract a predetermined constant)

So in the red row of the matrix, a value of 1 0 0 0 0 will keep the amount of red exactly the same. Lower value, less color; higher value, more color. The same goes for each channel row of the RGBA matrix: 0 1 0 0 0 for default green, 0 0 1 0 0 for default blue, and 0 0 0 1 0 for default alpha.

But what happens when you change other values? With 20 total color values to control the output RGBA channels, you can achieve a ton of different color effects. Try it out:

SVG
<feColorMatrix type="matrix" values="
  1 0 0 0 0
  0 1 0 0 0
  0 0 1 0 0
  0 0 0 1 0
" />

Changing each value in the matrix gives you a ton of control over the output of the effected element. You can create almost any color effect with these controls and <feColorMatrix>.

Shorthand types

Up until now we’ve been using <feColorMatrix> with the type matrix, but there are a few others as well that are much easier to use with fewer values to keep track of.

Saturate

The type saturate lets you adjust color intensity with a single values attribute. Lower values become more black and white while higher values become super vibrant.

SVG
<feColorMatrix type="saturate" values="1" />

Hue rotate

Like saturate, the type hueRotate uses a single values attribute. 0° is your starting point and 360° equals back where you started. Anywhere in between is similar to shifting the hue value of an hsl() color.

SVG
<feColorMatrix type="hueRotate" values="0" />

Luminance to alpha

The last type is luminanceToAlpha, which converts all the luminance (basically brightness) in an element to transparency.

White
White/Black
Color
SVG
<feColorMatrix type="luminanceToAlpha" />

Usage

To use any of the <feColorMatrix> filter effects, you need to put the SVG markup in your HTML somewhere.

SVG
<svg>
  <defs>
    <filter id="color-matrix-filter">
      <feColorMatrix type="luminanceToAlpha" />
    </filter>
  </defs>
</svg>

Then you can reference the id in CSS.

CSS
.color-matrix-filter {
  filter: url('#color-matrix-effect');
}

One last thing: SVG filters can thrash your computer’s hardware if not used sparingly, so take care to add will-change: filter on anything you’re planning to transition or animate. I’d also recommend content-visibility: auto if you know the element will be offscreen at some point.

All Done

<feColorMatrix> can replace many of the vanilla CSS filter effects and is way more powerful once you understand how it works. You can use apply small color corrections or entire mood shifts onto any element in the HTML/SVG DOM.

Experiment with different values to see how they affect the final result, and maybe even try chaining multiple <feColorMatrix> tags to compose hybrid looks.
